ABB XVC768115 3BHB007211R115 IGCT 门极驱动脉冲板 AC800PEC 中高压传动 & UNITROL 发电机励磁脉冲触发卡 电厂电力电子工控备件

Short Description:

现货供应 ABB XVC768115 门极脉冲驱动板，物料编码 3BHB007211R115，专为 IGCT 功率器件高精度触发信号输出设计，光纤隔离传输，适配 AC800PEC 控制器、UNITROL 励磁系统、ACS5000 中高压变频器，内置全套过流短路保护，全新原装库存、整机脉冲输出全功能老化测试拆机件，12 个月质保。...


下载到pdf

产品详情

产品标签

Module Type Introduction

XVC768115 3BHB007211R115 is the core pulse trigger output unit of ABB high-power power electronic control platform. It receives PWM timing instructions from main processor via Masterbus300 internal bus, generates optimized gate drive pulse waveforms and transmits to IGCT power rectifier/inverter units through fiber optical isolation interface. Optical medium completely isolates high-voltage power loop and low-voltage control circuit, eliminate ground loop surge and strong electromagnetic interference of medium voltage equipment. The module integrates multi-stage hardware protection circuit to detect IGCT short-circuit, over-current and gate signal loss, immediately lock pulse output to avoid power device breakdown. Full conformal coated PCB with strong anti-vibration and dust-proof performance, it is irreplaceable core maintenance spare part for thermal power, hydropower and metallurgical rolling mill excitation & medium voltage drive control cabinets.
XVC768115 3BHB007211R115 是 ABB 大功率电力电子控制平台核心脉冲触发输出单元，接收主控处理器通过 Masterbus300 内部总线下发的 PWM 时序指令，生成优化门极驱动脉冲波形，经光纤隔离接口传输至 IGCT 功率整流逆变单元；光介质完全隔离高压功率回路与低压控制回路，杜绝中压设备地环路浪涌、强电磁干扰窜入控制侧。板卡集成多级硬件保护回路，实时识别 IGCT 短路、过流、门控信号丢失故障，即刻封锁脉冲输出防止功率器件击穿；全板三防涂层 PCB，抗震防尘性能优异，是火电厂、水电站、冶金轧机励磁与中高压传动控制柜不可替代的核心维护备件。

Core Functions

  1. High-precision PWM gate pulse generation, optimized current waveform for IGCT to reduce switching loss and improve conversion efficiency
  2. 高精度 PWM 门极脉冲生成，适配 IGCT 优化电流波形，降低开关损耗、提升整机变换效率
  3. Duplex fiber optical isolation signal transmission, 3000VAC isolation withstand voltage, completely block high voltage leakage damage to control board
  4. 双工光纤隔离信号传输，3000VAC 工频隔离耐压，彻底阻断高压窜入损坏控制板
  5. Multi-channel synchronous pulse output, support multi-group IGCT power unit parallel synchronous triggering for excitation and medium voltage drive
  6. 多通道同步脉冲输出，支持多组 IGCT 功率单元并联同步触发，适配励磁、中高压传动成套设备
  7. Full hardware fault self-diagnosis, auto detect fiber break, pulse loss, IGCT short-circuit, over-current and backplane power abnormality
  8. 全套硬件自诊断，自动识别光纤断线、脉冲丢失、IGCT 短路、过流、背板供电异常
  9. Hard interlock pulse lockout output, immediately shut down gate drive signal when power device fault occurs to prevent over-current explosion
  10. 故障硬联锁脉冲闭锁输出，功率器件故障即刻关断门极驱动信号，避免过流炸管风险
  11. Masterbus300 dedicated high-speed internal bus, deterministic real-time communication with main control CPU without signal delay
  12. Masterbus300 专用高速内部总线，与主控 CPU 确定性实时通讯，无指令传输延迟
  13. Hot-swap plug-and-play design, ｒｅｐｌａｃｅ faulty pulse drive board without whole excitation/drive cabinet shutdown
  14. 机架热插拔即插即用，更换故障脉冲驱动板无需整套励磁 / 传动系统停机

Electrical Specifications

Backplane Power Supply: 24VDC rack backplane power, typical power consumption 14W
背板供电：24VDC 机架背板供电，整机典型功耗 14W
Pulse Output Carrier Frequency: Up to 10kHz adjustable PWM frequency
脉冲输出载波频率：最高 10kHz 可调 PWM 频率
Optical Fiber Interface: Duplex fiber Tx/Rx single-mode optical port
光纤接口：双工 TX/RX 单模光纤端子
Isolation Withstand Voltage: 3000VAC between power side and control circuit
功率侧与控制回路隔离耐压：3000VAC 工频耐压
Hardware Protection: Short-circuit auto shutdown, over-current lockout, over-temperature protection, surge & ESD multi-stage isolation
硬件防护：短路自动停机、过流闭锁、超温保护、浪涌静电 ESD 多级隔离防护
Control Calculation Cycle: ≤1ms pulse timing refresh cycle
脉冲时序刷新周期：≤1ms
