GE ITM11A8XJ036645 8 通道模拟量输入卡 MARK VI 燃气轮机 IO 模块电厂涡轮控制系统备件

Views :

Update time : 2026-07-09

Basic Information

Brand: General Electric Original USA, dedicated I/O card for Speedtronic MARK VI turbine control system

品牌：美国通用电气原厂，Speedtronic MARK VI 涡轮控制系统专用 IO 卡件

Model: ITM11A8XJ036645

型号：ITM11A8XJ036645

Product Type: 8-Channel Galvanic Isolated Analog Input Module

产品类型：8 通道电气隔离型模拟量输入模块

Compatible System: GE MARK VI gas turbine, steam turbine and combined cycle SIS safety control system

适配系统：GE MARK VI 燃气轮机、蒸汽轮机、联合循环 SIS 安全控制系统

Mounting Method: Standard VME rack plug-in installation with front and rear double connectors

安装方式：标准 VME 机架前后双接口插拔式安装

ITM11A8XJ036645 (5).png

Module Type Introduction

ITM11A8XJ036645 is standard field signal acquisition card for MARK VI rack, equipped with 8 fully galvanic isolated analog input channels. It receives continuous analog signals from field sensors including PT100 temperature probes, vibration transmitters, pressure transducers and speed pickups, converts analog signals into digital data via high-precision ADC chips and transmits to main processor through VME backplane bus. Triple modular redundant TMR design allows three identical ITM11A cards to run synchronous sampling and hardware voting, single channel fault will not trigger unit shutdown. Built-in complete self-diagnosis circuit, it is standard replacement spare part for power plant turbine safety monitoring loops.

ITM11A8XJ036645 是 MARK VI 机架标准现场信号采集卡，搭载 8 路完全电气隔离模拟输入通道，接收现场 PT100 温度探头、振动变送器、压力传感器、转速探头送来的连续模拟信号，通过高精度 ADC 芯片完成模数转换，经由 VME 背板总线上传数字数据至主控处理器。采用三重模冗余 TMR 设计，三块同款 ITM11A 同步采样硬件表决，单通道故障不会造成机组停机；内置完整硬件自诊断回路，是电厂涡轮机组安全监测回路标配替换备件。

ITM11A8XJ036645 (1).png

Core Functions

8 independent isolated analog input channels, compatible with 4~20mA and ±10VDC industrial standard sensor signals
8 路独立隔离模拟输入通道，兼容 4~20mA、±10VDC 工业标准传感器信号
High-precision ADC synchronous sampling, full channel data refresh within 10ms, ensure real-time monitoring of turbine operating conditions
高精度 ADC 同步采样，10ms 内完成全通道数据刷新，保障机组工况实时监控
Full galvanic isolation between each channel and backplane, suppress strong electromagnetic interference from turbine high-power equipment
通道与背板全电气隔离，隔绝机组大功率设备产生的强电磁干扰
Support TMR triple redundant parallel operation, hardware 2-out-of-3 voting to eliminate single-point failure risk of safety loops
支持 TMR 三重冗余并联运行，硬件三取二表决，消除安全回路单点失效风险
Auto hardware fault self-diagnosis, detect sensor open circuit, short circuit, over-range and board power failure, display fault codes via front panel LED
硬件自动自诊断，识别传感器断线、短路、超量程、板卡供电故障，面板 LED 显示故障代码
VME backplane high-speed bidirectional communication, upload real-time process data and fault information to main controller
VME 背板高速双向通讯，向主控上传实时工艺数据与故障信息
Field signal range configurable via ControlST software, flexible matching of different sensor measuring ranges without hardware modification
通过 ControlST 软件在线配置信号量程，无需改动硬件即可适配各类传感器测量区间
