Basic Information
品牌：ABB 瑞士原厂 UNITROL 励磁控制专用信号采集板Brand: Original ABB Switzerland, dedicated signal board for UNITROL excitation control series型号：KSD211BModel: KSD211B物料编号：3BHE022455R1101Part No.: 3BHE022455R1101产品类型：同步发电机电压电流同步测量采集板Product Type: Synchronous Generator Voltage & Current Synchronous Measurement Board适配系统：ABB UNITROL 5000、UNITROL 6000 励磁整流控制系统Compatible System: ABB UNITROL 5000, UNITROL 6000 excitation rectifier control system安装方式：标准 VME 机架插拔式安装Mounting Method: Plug-in installation for standard VME rack
Module Type Introduction
KSD211B 3BHE022455R1101 是 UNITROL 励磁系统核心模拟信号测量单元，板载高精度互感器隔离采样回路，同步采集发电机 PT 二次电压、CT 二次电流波形，实时计算有功、无功、功率因数、频率与相位差值，将同步测量数据上传主控板用于调压、无功分配、同期并网逻辑运算。内置失步、过频、欠频、断线保护逻辑，异常时输出闭锁信号禁止励磁调节与合闸操作，广泛用于火电、水电、燃气机组励磁柜故障替换。KSD211B 3BHE022455R1101 is core analog signal measurement unit of UNITROL excitation system. Equipped with high-precision transformer isolated sampling circuit, it synchronously samples PT secondary voltage and CT secondary current waveforms of generator, calculates active power, reactive power, power factor, frequency and phase difference in real time, and uploads synchronous measurement data to main board for voltage regulation, reactive power distribution and grid paralleling logic. Built-in loss-of-synchronism, over/under frequency and wire break protection logic, interlock signal will be output to lock excitation regulation and closing operation upon faults, widely used for spare part replacement of excitation cabinets in thermal, hydro and gas power units.
Core Functions
- 三相电压电流同步采集，实时计算机组有功、无功、功率因数、频率参数
- Three-phase voltage and current synchronous sampling, real-time calculation of unit active power, reactive power, power factor and frequency parameters
- 高精度相位同步检测，为同期并网模块提供精准频差、压差、相位差原始信号
- High-precision phase synchronization detection, provide accurate frequency, voltage and phase deviation raw signals for paralleling module
- 互感器电气隔离设计，高压二次回路与控制板完全隔离，杜绝强电窜入损坏主控单元
- Transformer galvanic isolation design, full separation between high-voltage secondary loop and control board to prevent high voltage leakage damage to main controller
- 全回路硬件自诊断，自动识别 PT 断线、CT 开路、采样回路短路、板卡供电异常
- Full-loop hardware self-diagnosis, auto detect PT wire break, CT open circuit, sampling short circuit and board power abnormality
- 故障闭锁输出，采样信号异常时触发励磁限制、同期合闸回路强制闭锁，防止机组误并网、过励磁
- Fault interlock output, trigger excitation limit and force closing circuit lock when sampling signal abnormal to avoid wrong paralleling and over-excitation
- VME 背板高速数据交互，测量参数、故障代码实时上传至主控，上位 HMI 远程监控
- High-speed VME backplane data exchange, measurement parameters and fault codes uploaded to main controller for remote HMI monitoring
- 温度漂移自动补偿，宽温工况下长期保持测量精度，减少现场校准频次
- Automatic temperature drift compensation, maintain stable measurement accuracy under wide temperature range to lower on-site calibration frequency
