ICS Triplex T8110B Trusted TMR 三重冗余处理器模块 SIL3 级 SIS 紧急停车安全控制系统备件

Short Description:

现货供应 ICS Triplex T8110B 核心 TMR 处理器，罗克韦尔 Trusted 安全仪表系统专用，三套独立 32 位处理器 2 取 3 硬件表决架构，支持在线热插拔、IRIG-B 时钟同步、SOE 毫秒事件记录，多路工业通讯接口，TÜV SIL3 功能安全认证，全新原装库存、整机全功能老化测试拆机件，12 个月质保。...


下载到pdf

产品详情

产品标签

Module Type Introduction

T8110B is the core safety control brain of Trusted SIS system, adopting full hardware TMR triple redundant architecture with three independent 32-bit high-speed processing cores running parallel logic calculation. Real-time hardware 2oo3 majority voting masks single-point circuit, chip or channel faults without safety logic interruption, fully compliant with IEC61508 SIL3 functional safety standard certified by TÜV. Integrated multi-channel serial communication, IRIG-B time synchronization interface and large-capacity SOE event buffer, it processes ESD emergency shutdown, fire & gas interlock, equipment trip protection logic, uploads fault and alarm data to DCS/SCADA via Modbus protocol. Hot-swap design allows single processor replacement without system outage, it is irreplaceable core maintenance spare part for oil refinery, offshore platform, chemical plant and power plant high-risk safety control cabinets.
T8110B 是 Trusted SIS 安全系统核心控制大脑，采用全硬件 TMR 三重冗余架构，内置三套独立 32 位高速处理内核并行执行逻辑运算，实时硬件 2 取 3 表决机制可屏蔽单路电路、芯片、通道故障，安全逻辑无中断运行，通过 TÜV IEC61508 SIL3 功能安全认证。集成多路串行通讯、IRIG-B 标准时钟同步接口与大容量 SOE 事件缓存，负责执行 ESD 紧急停车、火气联锁、设备跳机保护逻辑，通过 Modbus 协议向 DCS/SCADA 上传故障与报警数据；支持热插拔，单块处理器更换无需系统停机，是炼油厂、海上平台、化工厂、电厂高危安全控制柜不可替代的核心维护备件。

Core Functions

  1. Full TMR triple redundant hardware architecture, 2oo3 majority voting, eliminate single-point failure risk of safety interlock loops
  2. 全硬件 TMR 三重冗余架构，2 取 3 硬件表决，消除安全联锁回路单点失效风险
  3. Three independent 32-bit real-time processing cores, high-speed execution of ESD, F&G safety interlock logic
  4. 三套独立 32 位实时处理内核，高速执行 ESD 紧急停车、火气检测安全联锁逻辑
  5. IRIG-B002/122 standard time synchronization, 1ms precision SOE sequence of event recording for accident traceability
  6. IRIG-B002/122 标准时钟同步，毫秒级 SOE 事件顺序记录，便于事故溯源分析
  7. Multi-channel isolated serial communication ports, dual RS422/485 + auxiliary serial port, support Modbus master station protocol
  8. 多路隔离串行通讯端口，双路 RS422/485 + 辅助串口，支持 Modbus 主站协议对接第三方系统
  9. Complete hardware self-diagnosis, real-time monitor processor core, backplane bus, power and communication faults with front panel LED indicators
  10. 全套硬件自诊断，实时监测处理内核、背板总线、供电、通讯故障，面板 LED 状态指示
  11. Hot-swap plug-and-play design, ｒｅｐｌａｃｅ faulty processor without safety system shutdown or interlock loss
  12. 热插拔即插即用设计，更换故障处理器无需安全系统停机、联锁失效
  13. Support dual processor redundant hot standby, millisecond-level seamless takeover when main unit fails
  14. 支持双处理器冗余热备，主机故障时备机毫秒级无缝接管控制任务
  15. Large-capacity local event buffer, store thousands of fault, alarm and action records for post-failure analysis
  16. 大容量本地事件缓存，存储数千条故障、报警、动作记录，支撑事后故障复盘
